Network type
|
Stand-alone type
|
|
| Display |
128 × 64DOTS
|
16 CHAR × 4LINE
|
| Fingerprint sensor method |
An Optical Method
|
|
| Fingerprint sensor resolution |
450 dpi
|
|
| Fingerprint sensor scan area |
13.3×15.7 mm
|
|
| Certification Speed |
Within a second
|
|
| FRR (False Rejection Rate) |
0.1%
|
|
| FAR (False Acceptance Rate) |
0.0001%
|
|
| Process Capacity |
No limit
|
4,000 Cases
|
| Communication Speed |
IEEE 802.3 10 Mbps Ethernet
|
a
|
| A method of Network Access |
TCP/IP
|
a
|
| Communication port |
Ethernet
|
RS232/RS-485
|
| Voltage/power consumption |
DC 5V 1.0A/DC 12V 1.2 A
|
|
| Dimensions |
(W×H×D)200×133×37 mm
|
|
| Output |
12V Output, 1a,1c
|
|
| Emergency Control |
Emergency Control Applied Capacity
|
|
| Temperature Restrictions |
-150C~550C
|
|
| Humidity |
Under 90% RH
|
|
| Power |
AC 100-220 Free Voltage
|
|
| Option |
Video Phone Connection Capacity included
|
|
|
Black&White CCD Camera)/Battery Backup Power supply
|
||
